1080P night vision USB camera with STARVIS of IMX291 from Sony sensor. CK-IMX291
This is a 1080P low Lux USB camera module with superior low light and night vision.
Using a Sony STARVIS IMX291 2M (1920×1080) CMOS sensor.
Fixed focus with 105 degree field of view angle, the lens can be customized.
30FPS at full resolution 1920×1080.
High sensitivity, superior night vision performance at low brightness.
camera module ODM, OEM customization
Payment Terms: T/T
Delivery Time: 2-3weeks
Supply Ability: 500000 pieces/month
This night vision 1080P USB camera module should be used in night-vision device (NVD) which is also named as night optical/observation device (NOD), this high-end optoelectronic night vision USB camera module allows images to be produced under starlight in the night approaching total darkness. The image produced could be colorful, NVD (night vision device) with our imx291 night vision USB camera board is often used by the military and the law enforcement agencies. This low Lux night vision camera has a FN.1.0 optical lenses and night vision USB camera board with Sony sensor IMX291. If be used along with IR illuminator, making it an active night-vision device.
Share to:
This low light 1080P camera module is widely used in most applications: Teleconferencing system, video meeting, Video Conferencing, artificial intelligence (AI), robotics, Internet of things (IoT), machine vision, industrial automation, computer vision, educational equipment, medical imaging, agro-technological embedded devices, traffic monitoring system, etc.
Performance Parameter: (if you want customization, please download the table and fill in the parameter you want, password CKVISION)
|
Model |
CK-IMX291 |
REMARKS |
|
|
Image Sensor |
Imx291 |
|
|
|
Image Sensor Size |
1/2.8 |
|
|
|
Effective Pixels |
1920*1080 |
|
|
|
Pixel size |
2.9μm x 2.9μm |
|
|
|
Optical distortion |
≤0.5% |
|
|
|
Image sensor Data output |
Raw Data 10bits |
|
|
|
Video output format |
MPJG YUV2 |
|
|
|
Maximum Frame Rates and Resolution
|
1920*1080 @ 30 fps 1280×720 @ 30fps 640×480 @ 60 fps |
MJPG YUV2 |
|
|
SNR max |
TBD |
|
|
|
Dynamic range |
TBD |
|
|
|
Min. Illumination |
≥0.001LUX at F1.2 |
NO LED |
|
|
Digital interface |
5pin 1.25mm USB2.0 OTG |
|
|
|
Transfer rates |
480MB/S |
|
|
|
Power requirements |
5V±5% |
|
|
|
Storage temperature |
-20℃to70℃ |
|
|
|
operating temperature |
-10℃to60℃ |
|
|
|
Power Consumption |
NO LED |
Max 300mW |
|
|
IR-LED |
|
|
|
|
LED IR-850 |
NO |
|
|
|
OS |
WinXP/Vista/Win7/Win8 Linux with UVC（above linux-2.6.26） MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC |
|
|
|
Lens size |
M12 diameter；14mm height |
|
|
|
Lens Construction |
4G2P+IR |
|
|
|
F/NO |
1.0 |
|
|
|
EFL |
3.24mm |
|
|
|
FOV |
D:105°H:100°V:80° ±3° |
|
|
|
Shooting distance |
Manual zoom， 30cm-infinity |
|
|
